Internal I/O Connectors
- 1 x 24-pin AT x main power connector
- 1 x 8-pin AT x 12V power connector
- 1 x 4-pin AT x 12V power connector
- 1 x 4-pin flat AT x 12V power connector*
- 10 x SATA 6Gb/s connectors
- 3 x USB 2.0 connectors (supports additional 5 USB 2.0 ports)
- 2 x USB 3.0 connectors (supports additional 4 USB 3.0 ports)
- 2 x 4-pin CPU fan connectors
- 5 x 4-pin system fan connectors
- 1 x Clear CMOS jumper
- 1 x Front panel audio connector
- 2 x System panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 9 x V-Check connectors
- 1 x GO2BIOS button
- 1 x Power button
- 1 x Reset button
- 2 x Base Clock control buttons
- 2 x CPU Ratio control buttons
- 1 x OC Genie button
- 1 x Discharge button
- 1 x Multi-BIOS switch
- 1 x OC Genie mode switch
- 1 x Slow mode switch
- 1 x Base Clock step swtich
- 1 x PCIe CeaseFire switch
- 1 x 2-Digit Debug Code LED
- 1 x Wi-Fi/Bluetooth module connector
* Provides additional power to PCIe x16 slots
